Basic Info.
Model Grade | N52 | Catergory | Sintered |
Coating | Nickel | Process | Sintering-Machining-Coating-Magnetizing-Packing |
Grade | N-M-H-Sh-Uh-Eh | Performance | Permanent, Strong, Rust-Proof, Anti-Corrosion |
Certification | SGS | Application Area | Industry, Food Industry, Medical, Clothes Ect. |
Color | Nickel | Working Termprature | Max 150 Degree Celsius |
Material | Sintered NdFeB Magnet/Neodymium Magnet | Transport Package | Polybag/Inner Box/Carton or Customized |
Transport | by Air or by Ocean or by Express | Specification | Customized |
Tolerance in Size | +/-0.05mm | Origin | Dongguan |
Size | Costomized | HS Code | 8505111000 |
Type | Permanent and Strong | Production Capacity | 100000ton/Year |
Product Specification
Product Name: | Neodymium Magnet/NdFeB magnet/Permanent Neodymium Magnet | Working Temp.: | from 80ºC to 200ºC |
Product Materials: | NdFeB Magnets | Magnetic direction: | Customized |
Grade of Magnets: | N35-N52/35M-50M/33H-48H/33SH-45SH/30UH-38UH/28EH-35EH | Vertical pull force: | Depends on the size of the products |
Size of the products: | Customized from 1mm-100mm | Testing method: | The value of the magnetic pull force has some thing to do with the thickness of the steel plate and pull speed. Different application will have different result. |
Coat information and pictures
Category | Colour | Plating Thickness(UM) | Service temperature | Salt fog resistance |
NICUNI | silvery | 20-30 | ≤200ºC | >72hour |
NI | silvery | 10-30 | ≤2000ºC | >48hour |
ZN | Blue/color/silvery/black | 10-20 | ≤160ºC | >48hour |
Epoxy | black | 10-30 | ≤120ºC | >96hour |
Chemical nickel | silvery | 5-30 | ≤200ºC | >200hour |
Magnetized Direction
Our common magnetization directions are meticulously designed to cater to diverse applications:
1) Disc, cylinder, and ring-shaped magnets are expertly magnetized either axially or radially. This versatility allows them to serve a wide range of industrial applications with remarkable efficiency.
2) Block-shaped magnets are ingeniously designed for flexibility, capable of being magnetized through their thickness, length, or width. This adaptability ensures they meet the specific demands of engineering projects.
3) Arc-shaped magnets stand out with their unique ability to be magnetized radially, or through width or thickness, offering bespoke solutions for intricate design requirements.
Common Applications
1) Electronics - These magnets are indispensable in high-tech applications including sensors, hard disk drives, sophisticated switches, and electro-mechanical devices, significantly boosting the performance and reliability of every component.
2) Auto Industry - They are crucial for developing DC motors in both hybrid and electric vehicles, as well as in small high-performance motors and power steering systems, driving forward the innovation in automotive technology.
3) Clean Tech Energy - Our magnets play an essential role in enhancing water flow systems and wind turbines, contributing significantly to sustainable and eco-friendly energy solutions.
4) Medical - Magnets are critical in facilitating the operation of MRI equipment and scanners, thus supporting cutting-edge advancements in medical diagnostics and imaging technologies.
5) Magnetic Separators - Utilized in recycling processes, food and liquids quality control, and waste management, ensuring high efficiency and safety across various industries.
6) Magnetic Bearing - Used in highly sensitive and precise procedures within diverse heavy industries, our magnetic bearings ensure reliability and accuracy in demanding environments.
About Us
Guangdong DeCheng Magnetic Technology Co.,Ltd is a professional manufacturer and developer of various kinds of high strength, precision and special-shaped strong magnets.We have more than 500 sets of advanced magnet production and processing equipment, excellent management, technical personnel more than 20 people;is currently the only one from the smelting - formula - a blank a finished product one-stop production-oriented enterprises.Performance of our products: N35~N52, temperature: -40°~230", grades, N, M, H, SH, UH, EH, AH and so on. Shape: Square, round, perforated, runway, and high end shapes.
All of our products comply with ROHS, REACH and other safety certificates issued by SGS, an authoritative organization. Tecsun Magnetic has passed the latest authority iSO001;2000 quality system certification and ISO14001:2004 environmental management system certification.
Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with an irresistible force.
Packaging
Package:Our Magnetic Isolation Package is meticulously crafted to ensure the highest level of protection and integrity for magnets during transit.
Carton Dimension:The dimensions of 36*27*15CM are optimized for effective storage and handling, providing convenience and security.
Shipping:Expect swift and reliable delivery through our express services (UPS, FedEx, DHL, etc.), complemented by comprehensive air, rail, and sea options to meet your global distribution needs seamlessly.
FAQ
Q1: What are the standard dimensions of your products?
A: All products are fully customizable to meet your specific requirements. We implement precision engineering based on your technical specifications and application scenarios.
Q2: What technical parameters should I provide for project inquiries?
A: To ensure accurate quotation, please provide:
• Technical drawings with GD&T requirements (CAD/DXF preferred)
• Material specifications (grade and standard)
• Magnetization orientation (axial/radial/multi-pole)
• Surface treatment requirements (e.g., Ni-Cu-Ni, epoxy, passivation)
• Target quantities and INCOTERMS
Q3: What is your standard response time for inquiries?
A: Our engineering team maintains 7x24 technical support with guaranteed initial response within 12 business hours for complete RFQs. Complex projects may require additional 24-48 hours for comprehensive analysis.
Q4: How are pricing structures determined?
A: Pricing is calculated based on:
1.Material cost (grade-dependent)
2.Manufacturing complexity (tolerance class ±0.05mm~±0.5mm)
3.Order volume (MOQ: 100pcs standard)
4.Secondary processing requirements
Request a formal quotation by submitting your complete specifications.
Q5: Do you provide sample validation services?
A: Yes, we offer engineering samples for:
✓ Performance verification (Gauss testing available)
✓ Assembly fit-check
Submit sample requirements including validation criteria for customized arrangements.
Q6: What are your production lead times?
A: • Prototype samples: 3-5 business days (ex-works)
• Standard orders: 7-15 business days
Lead times commence after final approval of technical documents.
Q7: What payment terms do you accept?
A: We support multiple secure payment channels:
• T/T (50% advance, 50% before shipment)
• LC at sight (through accredited banks)
• Western Union, PayPal.
Full financial documentation including PI/CI provided upon order confirmation.
